ViewTec’s State-of-the-art 3D visualization

2010/09/14

Good news!!!! They’ve probably released this Geovisualization Engine long time ago (It used to be an ‘in-house’ software) but I have just realized. I worked with this state-of-the-art TerrainView 3D software for six months while I was working as a GIS Specialist in Cape Town (South Africa)… What does this software has that no one of other softwares I know have????. Rain, snow, clouds, wind… Athmosferic conditions!!!!  A very reliable package… I have just uploaded a video rendered directly from a pre-recorded flight path… I will try to make my own while I work with this personal license key they have provided me for one month… Here it is!!. Hope you like it mates!.

http://www.viewtec.net/

Products

ViewTec provides state-of-the-art interactive 3D visualization products andreal-time 3D Earth GIS.

TerrainView™

TerrainView™ is the free entry visualization product of ViewTec. TerrainView™ is an easy to use viewing tool and 3d editor capable of displaying the most popular 3d formats. It offers walk-through capabilities in real-time.TerrainView Extensions

Upgrade the free TerrainView product online to the different professional extensions:

TerrainView-Globe™

TerrainView-Globe™ extends TerrainView with unlimited GIS, multilayered elevation and image data import based on Earth and offers ultra-fast and high resolution rendering for GIS and simulation users.

TerrainView-RemoteControl™

The extension TerrainView-Remote Control™ offers an API to remotely manipulate points of interest and 3D objects of a 3D scene in real-time.

TerrainView-CMAX™

The extension TerrainView-CMAX™ consists in a high-end system for seamless multi-channel, multi-projections and visualizations on multiple screens and walls.

TerrainView-Video™.

TerrainView-Video™ is the extension to produce videos in a resolution higher than 640×480 e.g. PAL, NTSC and HDTV.

Advertisements

The SketchUp 3D API: Working with 3D geospatial data

2010/06/14

I hereby post this video by Matt Lowrie (Google). hope it’s interesting for you guys.

Alberto

Creating and personalizing KML code (placemarks).

2009/08/11

First of all, what is KML?. KML is a file format used to display geographic data in an Earth browser, such as Google Earth, Google Maps, and Google Maps for mobile. You can create KML files to pinpoint locations, add image overlays, and expose rich data in new ways. KML is an international standard maintained by the Open Geospatial Consortium, Inc. (OGC). You can choose wether authoring directly from Google Earth itself or you can try to understand the code and doing it by yourself… You can draw placemarks (using descriptive HTML to personalize them), ground overlays, paths, polygons… Let’s start with the placemark:

-> Simple placemark

<?xml version=”1.0″ encoding=”UTF-8″?>
<kml xmlns=”http://www.opengis.net/kml/2.2″&gt;
  <Placemark>
    <name>Simple placemark</name>
    <description>Attached to the ground. Intelligently places itself
       at the height of the underlying terrain.</description>
    <Point>
      <coordinates>-122.0822035425683,37.42228990140251,0</coordinates>
    </Point>
  </Placemark>
</kml>

simpleplacemark

  • An XML header. This is line 1 in every KML file. No spaces or other characters can appear before this line.
  • A KML namespace declaration. This is line 2 in every KML 2.2 file.
  • A Placemark object that contains the following elements:
    • A name that is used as the label for the Placemark
    • A description that appears in the “balloon” attached to the Placemark
    • A Point that specifies the position of the Placemark on the Earth’s surface (longitude, latitude, and optional altitude)
  • -> Floating placemark

    <?xml version=”1.0″ encoding=”UTF-8″?>
    <kml xmlns=”
    http://www.opengis.net/kml/2.2” xmlns:gx=”http://www.google.com/kml/ext/2.2” xmlns:kml=”http://www.opengis.net/kml/2.2” xmlns:atom=”http://www.w3.org/2005/Atom“>
    <Document>
     <name>Floating placemark.kml</name>
     <Style id=”downArrowIcon”>
      <IconStyle>
       <Icon>
        <href>http://maps.google.com/mapfiles/kml/pal4/icon28.png</href&gt;
       </Icon>
      </IconStyle>
     </Style>
     <Placemark>
      <name>Floating placemark</name>
      <description>Floats a defined distance above the ground.</description>
      <LookAt>
       <longitude>-122.0839597145766</longitude>
       <latitude>37.42222904525232</latitude>
       <altitude>0</altitude>
       <range>500.6566641072245</range>
       <tilt>40.5575073395506</tilt>
       <heading>-148.4122922628044</heading>
      </LookAt>
      <styleUrl>#downArrowIcon</styleUrl>
      <Point>
       <altitudeMode>relativeToGround</altitudeMode>
       <coordinates>-122.084075,37.4220033612141,50</coordinates>
      </Point>
     </Placemark>
    </Document>
    </kml>

    floatingplacemark

    -> Extruded placemark

    <?xml version=”1.0″ encoding=”UTF-8″?>
    <kml xmlns=”
    http://www.opengis.net/kml/2.2” xmlns:gx=”http://www.google.com/kml/ext/2.2” xmlns:kml=”http://www.opengis.net/kml/2.2” xmlns:atom=”http://www.w3.org/2005/Atom“>
    <Document>
     <name>Extruded placemark.kml</name>
     <Style id=”globeIcon”>
      <IconStyle>
       <Icon>
        <href>http://maps.google.com/mapfiles/kml/pal3/icon19.png</href&gt;
       </Icon>
      </IconStyle>
      <LineStyle>
       <width>2</width>
      </LineStyle>
     </Style>
     <Placemark>
      <name>Extruded placemark</name>
      <description>Tethered to the ground by a customizable
              &quot;tail&quot;</description>
      <LookAt>
       <longitude>-122.0845787421525</longitude>
       <latitude>37.42215078737763</latitude>
       <altitude>0</altitude>
       <range>365.2646606980322</range>
       <tilt>40.55750733918048</tilt>
       <heading>-148.4126684946234</heading>
      </LookAt>
      <styleUrl>#globeIcon</styleUrl>
      <Point>
       <extrude>1</extrude>
       <altitudeMode>relativeToGround</altitudeMode>
       <coordinates>-122.0857667006183,37.42156927867553,50</coordinates>
      </Point>
     </Placemark>
    </Document>
    </kml>

    extrudedplacemark

    If instead of regular <description>

    <description>Attached to the ground. Intelligently places itself
           at the height of the underlying terrain.</description>

    simple

    you use the CDATA element, you can write HTML and avoiding Google Earth from parsing the code incorrectly:

     <description>
            <![CDATA[
              <h1>CDATA Tags are useful!</h1>
              <p><font color=”red”>Text is <i>more readable</i> and
              <b>easier to write</b> when you can avoid using entity
              references.</font></p>
            ]]>
          </description>

     cdata

    Rich Interface Design with Adobe FLEX Builder.

    2009/05/27

    Rich Interface Design (RID) is the best way to work alongside a developer. You don’t have to design and afterwards the developer tries to transform it into code or upside down you dont have to try to understand developer’s code and at the same time doing your best to get a beautiful and outstanding application… with FLEX you guys are working at the same workspace… everything you design is automatically written into code and you can share it with the developer working with you… isn’t it fantastic???…

    Let me please show you some examples…




    Hope you guys like it.

    Alberto Concejal
    BA Geography-MSc GIS and Remote Sensing-Multimedia Designer
